Modern Ceiling Light Exact Dimensions, 7.9 in Ball Shade

The modern ceiling light exact dimensions are 7.9 in (20 cm) across the ball shade, 4.7 in (12 cm) across the ceiling canopy, and 9.4 in (24 cm) from the ceiling down to the bottom of the ball. That last number decides the job, because 9.4 in (24 cm) is a drop rather than a flush profile, and it comes out of your headroom before anything else does. Houseland lists it as a surface mounted, hardwired fixture, so the 4.7 in (12 cm) canopy sits flat against the plaster and covers a standard 4 in (10 cm) round ceiling box with about 0.35 in (9 mm) to spare on each side.

Most pages answering this question hand you a size chart for the whole category and never print this fixture's own three numbers. The three that matter are published, and the fourth number, the one about your ceiling, is the one you have to go and measure yourself.

What are the modern ceiling light exact dimensions?

Three numbers, and they hold across the Green, Blue, Yellow and Pink shades. The shade is 7.9 in (20 cm) at its widest point, the canopy is 4.7 in (12 cm), and the fixture stands 9.4 in (24 cm) tall measured from the ceiling surface down. Those three tell you something useful when you put them together: if the ball is as tall as it is wide, the canopy and the short stem account for the remaining 1.5 in (4 cm). Almost the whole fixture is ball, and the part actually touching your ceiling is a 4.7 in (12 cm) white disc.

The canopy is the number people skip and then regret on a Saturday afternoon. A 4.7 in (12 cm) disc covers a 4 in (10 cm) round box and nothing wider, so if your old fitting left a ring of clean paint on the ceiling, measure that ring before the old one comes down. The 7.9 in (20 cm) shade is the widest part of the assembly, but it sits below the canopy rather than against the plaster, so it hides nothing at all.

Does 9.4 in of drop clear a low ceiling?

On a standard 8 ft (244 cm) ceiling, yes, with 86.6 in (220 cm) of clear air under the ball. Take 9.4 in (24 cm) off 96 in (244 cm) and that is what is left, which puts the bottom of the shade 6.6 in above the head of a standard 80 in (203 cm) door frame. I keep 84 in (213 cm) as my own floor for anything hanging over a route people walk, and 86.6 in clears that by 2.6 in. At 9.4 in (24 cm) tall this is a short drop and not a flush mount, and the difference shows up on an 8 ft ceiling long before it shows up in the photographs.

Below 8 ft the arithmetic turns on you quickly. A 7 ft 6 in (229 cm) ceiling leaves 80.6 in (205 cm) under the ball, level with the top of the door frame you just walked through, and a tall person in a narrow hall will feel that before they ever hit it. That is the point where I would stop and read through the options that suit ceilings under 8 ft instead of arguing with the tape, because a ball on a stem is the wrong shape for 90 in (229 cm) of ceiling.

The ball itself is adjustable, which does not change the 9.4 in (24 cm) at all but does change where the light lands. If the fixture ends up within 24 in (61 cm) of a wall, aim the opening along the corridor rather than straight down, or you will light one patch of skirting board very well.

Where does a 7.9 in shade actually work?

Hallways, kitchens, entries, bedrooms, closets, dry sunrooms and covered porch ceilings, all of which the product page lists. No wet rating is documented for it, so a covered porch soffit is as far outdoors as it goes, and an exposed balcony edge that takes rain is no place for a 4.7 in (12 cm) hardwired canopy. Anywhere in that list, the same 9.4 in (24 cm) comes off whatever your ceiling measures.

On a balcony ceiling, measure the soffit before you order, because a covered balcony often sits lower than the rooms behind it, and 9.4 in (24 cm) off 84 in (213 cm) leaves 74.6 in (189 cm), which is head height for anyone over 6 ft 2 in (188 cm). In an entry, put it where the door swing clears it, since a 7.9 in (20 cm) shade at 86.6 in (220 cm) is exactly the height a raised umbrella finds. In a closet, check the gap above the top shelf first, because the fixture wants 9.4 in (24 cm) of clear air below the ceiling and shelving is usually the thing that takes it.

How do I check the fit before the electrician arrives?

Six measurements, and a tape plus a torch will get you through them in about 10 minutes. Do them in this order, because the first one that fails saves you the other five.

1. Kill the breaker and confirm the old fitting is dead, and give a hot bulb 10 minutes to cool before you put a hand near it. This one is hardwired and surface mounted, so there is no plug to pull.
2. Measure the existing ceiling box. A standard round box is 4 in (10 cm) across and the canopy is 4.7 in (12 cm), which gives you 0.35 in (9 mm) of cover per side and not a millimetre more.
3. Measure floor to ceiling in the exact spot the fixture goes, then subtract 9.4 in (24 cm). Under 84 in (213 cm) of clearance, you will resent it in a walkway.
4. Measure the corridor width. In a 36 in (91 cm) hall, a 7.9 in (20 cm) shade leaves 14 in (36 cm) of bare ceiling on each side, which reads as deliberate rather than mean.
5. Find out what the box is fixed to. Joists on 16 in (41 cm) centres carry a surface mounted fixture without argument, while a box floating in plasterboard wants a brace fitted first.
6. Count the carton: one body with canopy and shade assembly, plus the mounting hardware the product page shows. No lamp wattage is published anywhere on the page, so read the label on the fixture before the canopy goes up and the electrician packs the ladder away.

Flush mount or short drop: which one fits a hallway?

A flat flush mount fits better under 8 ft (244 cm), and this ball fits better above it. The comparison is four measurements wide, and three of them are already printed.

The ball earns its 9.4 in (24 cm) back by aiming the opening down. In a 36 in (91 cm) hall you want light on the floor and the door handles rather than a wash across the ceiling, and a 7.9 in (20 cm) shade pointed downward does that with one fixture where a wide flat disc often needs two. If you are pricing the flat versions too, the flush mount roundup carries those numbers, and the wall lamps collection has the rest of the ceiling and wall fittings in one place.

What spacing works down a hall or over a staircase?

About 6 ft (183 cm) apart, so a 20 ft (610 cm) hallway takes three of them with 4 ft (122 cm) of run at each end. Two in that same 20 ft (610 cm) hall leaves a dark patch in the middle that no 7.9 in (20 cm) shade is going to fill. Houseland ships all four shades at the same 7.9 in (20 cm) width and 9.4 in (24 cm) height, so color is a decorating decision and not a fit decision.

Stairs are where the tape lies to you. Measure from the tread directly under the fixture rather than from the floor at the bottom, because a stairwell ceiling can read 12 ft (366 cm) over the landing and 7 ft (213 cm) over the top step. The 9.4 in (24 cm) drop comes off the smallest of those numbers, never the average.

Over a run of 24 in (61 cm) deep base cabinets, one 7.9 in (20 cm) shade is an accent and not the task light. That is the mistake I see most often in a room where a single ceiling fitting is doing all the work, and adding color to the shade does not add light to the worktop.

From the shop

Modern Ceiling Light, Adjustable Ball LED Hallway Fixture, 4 Colors

A 4.7 in (12 cm) canopy, a 7.9 in (20 cm) ball and 9.4 in (24 cm) of total height, surface mounted. Green, Blue, Yellow and Pink are all the same size, so the fit decision stays the same whichever one you pick.

See the modern ceiling light

What would I buy first?

Measure the ceiling, then pick the color, and buy this one if the tape says 96 in (244 cm) or more. At 99.99 USD it is an accent fixture with a 7.9 in (20 cm) colored ball on it, which is what you want over a hall, an entry or a small kitchen, and not what you want as the only source in a 12 ft (366 cm) room. The three sizes are printed on the product page, which is more than most of the pages currently answering this question manage. On a 90 in (229 cm) ceiling I would not hang it at all, and I would say that at 11pm with the old fitting already off the ceiling and the breaker still down.
