Check 5 things on an up down wall light listing: how many bulbs and which base, how wide the top and bottom openings are, how far it projects from the wall, whether it is rated for the wall you have, and what the body is made of and screws to. The numbers to look for are 2 G9 sockets at about 5W of LED each, a projection under 4 in (10.2 cm) for a corridor, a dry-location rating for indoors, and a hardwired bracket on a standard box. Houseland's fluted resin sconce reads 6.5 in (16.5 cm) tall, 5.5 in (14 cm) wide and 3.1 in (8 cm) deep, with 2 G9 sockets, open top and bottom, and an AC 90-260V hardwired bracket.
Listings for this shape look alike in the photo and differ in the sockets, the openings and the depth, which is where the wash width, the corridor clearance and the bulb bill are decided. Each check below gives the figure, where it comes from, and the case where it changes.
How many bulbs does an up down wall light need, and what base?
Two sockets, one firing up and one down, with a G9 base and about 5W of LED in each, is the layout to look for; a single bulb behind a divided shade splits one source 2 ways and the top wash comes out weaker than the pool below. Houseland's sconce ships with no bulbs, takes 2 G9 base bulbs, recommends a 5W LED capsule per socket, and notes that standard US 120V G9 LED bulbs fit the sockets.
| Check | Number to look for | What it decides |
|---|---|---|
| Bulbs | 2 sockets, G9 base, about 5W LED each, roughly 500 lumens per capsule | Brightness, dimming, running heat |
| Openings and height | Open top and bottom; centre 60 to 72 in (152 to 183 cm) from the floor | Wash width, ceiling hot spot |
| Projection | 4 in (10.2 cm) or less from the wall on a corridor | Shoulder clearance, ADA 307.2 |
| Location rating | Dry location for indoors; damp or wet marking anywhere else | Whether it is safe on that wall |
| Body and bracket | Resin or metal shade over a bracket on a wall box; luminaires over 6 lb (2.7 kg) need a marked box | Weight, cleaning, bulb changes |
G9 is a bi-pin base with the pins 0.35 in (9 mm) apart, listed by Wikipedia's bi-pin lamp base table as IEC 7004-129-3, a halogen base at 120V in the US and 230V in Europe that is also used for LED lamps. Westinghouse's 5W G9 dimmable LED is a fair reference for what a 5W capsule does: 500 lumens, 120V, 3000K, CRI 80, a 25,000 hour rating, 2.13 in (5.4 cm) overall length, and it is marked approved for damp locations and for totally enclosed fixtures. Votatec's G9 guide puts a 40W halogen G9 at roughly 400 to 500 lumens, so a 5W LED capsule replaces a 40W halogen without the heat, and warns that G9 LED bodies vary in length and width even though the pins are standard.
Two 5W capsules give about 1,000 lumens of bulb output per sconce, before the shade takes its share, which is why a 2-socket fixture beats a 1-bulb one on a dark landing. What leaves the shade is smaller than what the box says, and how many lumens a wall sconce actually puts out walks through the DOE fixture figures that explain the gap. Dimming is the bulb's job and the dimmer's, not the fixture's: the sconce has no electronics, so fit dimmable G9 capsules on a compatible dimmer circuit and the wash dims. Two 5W capsules make a 10W load, which LEDYi's comparison says clears a trailing edge dimmer's 5W to 10W minimum but not a leading edge dimmer's 20W to 40W, and Lutron's Application Note 487 lists the symptoms of an under-loaded dimmer as glow when off, flashing, reduced range and flicker.
How wide will the wash be, and how far below the ceiling should it sit?
The openings set the wash width at the shade, and the distance to the ceiling sets how far that wash spreads before it hits something; put the centre at 60 to 72 in (152 to 183 cm) from the floor and the top of a 6.5 in (16.5 cm) shade lands 21 to 33 in (53 to 84 cm) below an 8 ft ceiling, which is enough run for the beam to open up. Modern.Place's sconce height guide gives that 60 to 72 in (152 to 183 cm) range for most rooms, 66 to 72 in (168 to 183 cm) for tall or vaulted ceilings, and hallway fixtures spaced every 6 to 8 ft.
The light leaving an open top fades with distance by the inverse-square law, so a shade sitting 12 in (30 cm) below the ceiling throws a small hot patch and one sitting 30 in (76 cm) below it throws a soft, wide one about 4 times dimmer per square inch. Wikipedia's architectural lighting design fixture table separates the 2 effects you can get from a wall: a wall grazing fixture is placed close to the wall to enhance a textured surface, and a wallwasher lights from ceiling to floor and flatly illuminates the wall. An open-top-and-bottom shade grazes, because the light runs along the plaster from a source nearly flush with it, which is why brushed plaster and limewash look good under this fixture and a badly patched wall looks worse.
Read the opening sizes against the body size. On the fluted sconce the face is 5.5 in (14 cm) wide, so the wash starts at that width and the ribbed edge throws soft vertical shadows with warm bulbs, and the listing rates the coverage at 5 to 10 square meters, about 54 to 108 sq ft, which is one landing or one stretch of corridor, not a living room. Mount it lower than 60 in (152 cm) and the top wash grows while the lower pool hits the floor early; mount it above 72 in (183 cm) and the upper wash flattens against the ceiling into a bright bar.
How far can it stick out in a corridor?
Keep the projection at 4 in (10.2 cm) or less on any corridor wall, because that is the limit ADA 2010 section 307.2 sets for a protruding object, and it is a sensible limit in a house even where the ADA does not apply. The text on Cornell's CFR mirror reads: objects with leading edges more than 27 in (68.6 cm) and not more than 80 in (203 cm) above the finish floor shall protrude 4 in (10.2 cm) maximum horizontally into the circulation path. A sconce centred at 60 to 72 in (152 to 183 cm) sits squarely inside that band, which is exactly where a shoulder or a carried box meets it.
Corridor width is regulated too: IRC R311.6 requires a hallway to be not less than 3 ft (0.9 m) wide, and E3903.3 in the IRC chapter 39 mirror requires at least one lighting outlet controlled by a listed wall-mounted control device in hallways and stairways. Houseland's sconce projects 3.1 in (8 cm) from the wall, so it clears the 4 in (10.2 cm) rule with 0.9 in (2.3 cm) to spare on a 3 ft (0.9 m) corridor, and the hardwired bracket lets it take the switched outlet the code already requires in that hallway.
Width matters more on a stair wall. A 5.5 in (14 cm) face fits between a handrail bracket and a picture frame; a 10 in (25 cm) drum does not, and on a stair the fixture also has to clear the swing of the handrail hand. Measure the wall from the nearest door casing or rail bracket before buying, and reject any shade wider than that gap minus 2 in (5 cm).
From the shop
Fluted Resin Hallway Sconce, Up Down Wall Light in 4 Colors, Two G9 Bulbs
Fluted resin up down sconce, 6.5 in (16.5 cm) tall, 5.5 in (14 cm) wide and 3.1 in (8 cm) deep, with 2 G9 sockets (bulbs not included, 5W LED each recommended), hardwired on AC 90-260V, in ivory, olive, terracotta or charcoal.
View the fluted up-down sconce — 4 colours & current priceIs it rated for the wall you want it on?
An indoor sconce with no location marking is a dry-location fixture, and that rules out showers, uncovered porches and any wall that gets condensation. The definitions come from NEC Article 100, reproduced in H.E. Williams' environmental conditions sheet: a dry location is one not normally subject to dampness or wetness, a damp location is protected from weather but subject to moderate moisture, such as roofed open porches and some basements, and a wet location is one subject to saturation or unprotected from weather. The same sheet quotes the marking rule: luminaires in wet locations must be marked Suitable for Wet Locations, and those in damp locations Suitable for Wet Locations or Suitable for Damp Locations.
The fluted sconce's product page answers the outdoor question with a plain no: it is an indoor up down wall light for dry walls, carries no waterproof rating, and should stay out of showers, uncovered porches and anywhere it would be rained on. A resin body and an open top do not mind humidity from a bath down the hall; they do mind a window that runs with condensation every winter morning, because water pools in an open shade and drips onto the socket.
The case where the answer changes is a covered entry inside the thermal envelope, a porch enclosed with glass, or a mudroom: those are dry by the definition if they are heated and ventilated, and damp if they are not. When in doubt, buy a fixture marked for damp locations for that wall and keep the unmarked one for the landing.
What is the body made of, and what does it screw to?
Molded resin over a metal bracket is the combination to look for on a fixture this size, because resin keeps the weight low and the matte surface takes no fingerprints, and the bracket is what actually carries the load. Houseland's sconce is molded resin with a ribbed fluted texture and a matte finish over a metal mounting bracket; the bracket screws to the wall box first, the wires connect, and the resin shade clips over it with no visible fixings.
The box behind the bracket has its own rule. IRC E3905.6.1, in the Texas 2024 chapter 39 mirror, says a box at a luminaire outlet on a vertical surface must be marked inside with the maximum luminaire weight it may support if that is other than 50 lb (22.7 kg), and its exception allows a vertically mounted luminaire weighing not more than 6 lb (2.7 kg) to sit on other boxes or plaster rings provided it is secured with not fewer than 2 No. 6 or larger screws. The listing publishes no weight, so if your wall has an old shallow box rather than a listed luminaire box, ask for the weight before ordering and keep to the 6 lb (2.7 kg) exception.
A resin shade also fails differently from cast plaster: it does not chip if a ladder knocks it, and it can be lifted off the bracket to change a capsule without tools. Cast plaster sconces need painting and cannot be unclipped; metal ones show every fingerprint on a stair wall. If there is no box at all, a plug-in or battery route is the honest answer, and lighting a dark corner without wiring covers what those can and cannot do.
Who should buy which colour, and who should skip it?
Buy ivory for a dark corridor, charcoal for a wall you want the fixture to read as an object by day, and olive or terracotta where the wall is warm already; the product page says ivory reflects the most light, olive and terracotta trade a little brightness for warmth, and charcoal is the boldest by day and the most dramatic when lit. The 4 finishes sit in the wall lamps collection beside the globe and macaron sconces that throw light sideways instead, which is the right comparison if your wall is short.
Who should skip it: anyone who needs to read by it. A 2-way wash puts light on the wall above and the floor below and very little at the horizontal, so a bedside reader wants a shaded or swing-arm fixture and a page-level beam, and wall sconce vs table lamp is the better decision for that job. Anyone with an 8 ft ceiling and a fixture centre above 72 in (183 cm) gets a bright bar on the ceiling and a dim wall; drop the centre, or pick a downlight-only shade.
Anyone who can see the socket from the sofa should also pause: an open bottom shows the capsule from below on a low wall, and a 500 lumen point source at eye height is a glare problem, the same one described in why you can see the bare bulb of a wall light from bed. Mount at 60 in (152 cm) or higher, choose frosted capsules, and the open bottom shows a glow, not a filament.
